Specifications
| XS | S | MS | ML | L | |
|---|---|---|---|---|---|
| Number of cells | 62 | 62 | 62 | 62 | 62 |
| Projected area (m2) | 17.8 | 19.4 | 20.5 | 21.7 | 23 |
| Flat area (m2) | 21.1 | 23.1 | 24.4 | 25.7 | 27.3 |
| Projected span (m) | 8.9 | 9.3 | 9.5 | 9.8 | 10.1 |
| Flat span (m) | 11.3 | 11.8 | 12.1 | 12.5 | 12.8 |
| Projected Aspect Ratio | 4.4 | 4.4 | 4.4 | 4.4 | 4.4 |
| Flat aspect ratio | 6 | 6 | 6 | 6 | 6 |
| Root Chord (m) | 2.35 | 2.45 | 2.52 | 2.59 | 2.67 |
| Glider Weight* (kg) | 3.7 | 4.0 | 4.2 | 4.5 | 4.8 |
| In-flight weight range (kg) | 58-70 | 65-85 | 75-95 | 85-105 | 95-115 |
| EN / LTF | C | C | C | C | C |
* Weights may vary up to 50gm per size due to slight variations in the manufacturing of the fabric used.
Materials
- Top Surface Cloth: Dominico N20D MF
- Bottom Surface Cloth: Porcher 7000 E71
- Rib cloth: Porcher Skytex 9017 E29A / 7000 E29
- Upper lines: Edelrid 8000U-130/90/70/50kg Aramid
- Mid lines: Edelrid 8000U-130/90kg Aramid
- Lower Lines: Edelrid 8000U-230/190/130Kg Aramid
